Automatic Servo Motor Piston Chilli Oil Filling Packaging Machine

Automatic Chilli Oil Filling Packaging Machine

The automatic chilli oil filling machine is specifically designed for filling granular and high-concentration chili oil and other similar sauce products, such as bean paste, peanut butter, sesame paste, jam, butter hot pot base, red oil hot pot base, and other substances with high oil content. This machine is ideal for materials with uneven particles, making it perfect for packaging chili oil, as well as other sauces with similar properties.

Equipped with PLC control, the chilli oil filling machine offers a user-friendly interface where the filling bottle and discharge nozzle are fixed, while all other functions can be controlled via a touch screen. This machine not only offers the advantages of a standard automatic servo piston filling machine but also broadens the range of fillable materials. It is particularly effective for handling filling materials that contain particles or long strips of solid content, making it an excellent choice for chili oil and other sauce products.

Key Features

1.Each filling head has an independent flow control device, making precise adjustments quick and easy.

2.The machine’s material contact parts can be made from food-grade materials, tailored to the product’s characteristics, ensuring compliance with GMP standards.

3.Features include regular filling, no-bottle-no-filling, filling quantity tracking, and production counting functions.

4.Easy maintenance with no special tools required.

5.Equipped with drip-tight filling heads to prevent leakage.

6.Includes a photoelectric sensor, mechatronic filling adjustment system, and material level control feeding system.

7.Stainless steel frame with plexiglass safety covers.

8.Control system: PLC and electronic-pneumatic controlled.

9.Capacity adjustment: All cylinders are automatically adjusted, with individual adjustment options for each cylinder.

Main Parameter

Main Components of a Piston Filler

1.The Hopper: Holds large quantities of the product, ready for filling into containers.

2.The Piston: Draws product from the hopper into the piston cylinder, ensuring smooth and efficient material transfer.

3.The Piston Cylinder: Maintains a fixed interior volume, ensuring precise and consistent fill levels during each cycle.

4.The Valve: Regulates the flow of the product, opening to allow filling and closing to prevent overflows.

5.The Nozzles: Accurately dispense the product from the piston cylinder into containers.

Product Details

After-sale Service

1.Installation:
Our skilled technicians are available to travel and install the piston filler machine. The service fee includes installation, travel, meals, and other related expenses.

2.Training:
To ensure the optimal performance of your bottle filling machine, we provide on-site or factory training for dealers, machine operators, engineers, and technicians.

3.Guarantee:
We offer efficient repair services for the bottle washing machine, along with a one-year quality assurance period, parts supply, and fast responses for troubleshooting.

4.Consulting Service:
Take advantage of our free consultation service. Our professional sales team will help you find the best solution, including CAD drawings for the liquid filling machine design.

5.Technical Support:
Enjoy long-term, reliable technical support. Reach out to us via email or phone, and we’ll provide prompt assistance, ensuring peace of mind for you.

6.Spare Parts:
We include a set of vulnerable spare parts for the filling machine at no extra cost during transportation. Additionally, you can order a wide range of high-quality spare parts anytime you need them.
