Automatic High Speed Ionized Air Rinser For Bottles Ionizing Can Rinser

Minimum Order Quantity : 1 Price : 9000USD/set to 30000USD/set
Packaging Details : Wooden box Delivery Time : 40 working days
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 100SETS
Place of Origin: China Brand Name: N PACK
Certification: CE

Detail Information


Ionizing Can Rinser


ionized air rinser


ionized air bottle rinser

Product Description

Automatic High Speed Ionized Air Rinser For Bottles

This bottle rinsing machine is primarily designed to cleanse the interiors of bottles and jars of various shapes using ionized air flushing, ensuring compliance with production process standards. Additionally, it incorporates a UV tunnel for initial bottle sterilization.

Customized to suit various products and required capacities, this bottle rinsing machine can be tailored accordingly. Additionally, optional components such as bottle unscrambler machines, filling machines, capping machines, labeling machines, ink coding machines, and packaging machines can be added and combined as needed.


Working Principle:
Air bottle rinsers offer an effective method for safely eliminating dust and fine particles from containers prior to filling. This system is particularly adept at removing loose contaminants that may have accumulated during transportation or storage. Widely used in beverage filling, food, and pharmaceutical industries, the ionized air rinser automatically positions containers under an air nozzle equipped with both ionized air-jet and vacuum capabilities. Initially, the bottle receives bursts of HEPA filtered ionized air to dislodge particles from the container's surface, followed by a vacuum sequence that extracts particulates into a self-contained filter unit.


Key Features of the Bottle Rinsing Machine:
1. The automatic ionized air rinser is specifically engineered for pre-filling rinsing of bottles and jars, combining ionized air flushing with UV sterilization.

2. Optional components such as bottle unscrambler machines, drying tunnels, filling machines, capping machines, labeling machines, ink coding machines, and packaging machines can be seamlessly integrated as needed.

3. The entire washing system operates as a fully automatic setup, featuring PLC control, a 7-inch touch screen interface, and renowned electrical and pneumatic components from Simens, Schneider, Airtac, and Omron.

4. Constructed from high-quality 304/316 stainless steel and alloy aluminum, all machines ensure durability and hygiene.

5. Easily adjustable to accommodate various bottle sizes.

6. Customizable water rinsing with air flushing capability.




Power supply voltage 220V/50~60Hz
Power 1.5KW
Use air pressure 0.4-0.6Mpa
Bottle cleaning speed 1800-2000bottle/hour
Use air source Ionized air, Compressed air and vacuum
Adapt to bottle type glass bottle or plastic bottle
Weight about 450kg
Dimensions L1500 x W1000 x H1900mm

Why Use Air Bottle Rinser

Rinsing machinery ensures product integrity by removing contaminants from bottles before filling, vital for food and beverage packaging. While wet rinsers are common, they generate waste. Air rinsing has gained popularity for its efficiency and minimal waste output. It uses blasts of clean air to dislodge debris from bottles, avoiding residual water or solution post-fill. For challenging bottle shapes, bottle vacuums offer an alternative, utilizing clean air blasts and vacuum suction to remove debris without removing bottles from the conveyor belt.
