Automatic Cardboard Box Labeling Machine
The Cardboard Box Labeling Machine is a fully automated system designed for precise labeling on cardboard boxes and cartons. Equipped with a multi-label feeder, it applies labels to the front, back, top, bottom, and corners of various box shapes, ensuring efficiency and accuracy.
This machine features an advanced PLC-based control system and high-precision sensors for consistent and adjustable labeling, even on uniquely shaped boxes. Its dynamic marking system supports multiple labeling requirements, enhancing productivity.
The NPACK Label Dispensing System synchronizes labeling components, allowing smooth speed adjustments for accurate labeling during start-up, stopping, and deceleration. The energy-efficient design ensures high output with low power consumption.
Ideal for industries like pharmaceuticals, cosmetics, healthcare, and food processing, this Cardboard Box Labeling Machine delivers fast, precise, and automated labeling, streamlining production and improving packaging quality.
Main Features:
- No Carton, No Label Function
- GMP-Compliant Design
- Smooth & Highly Accurate Label Placement
- Durable Stainless Steel Frame & Door
- Automatic Label Length Measurement
- Advanced PLC-Controlled Servo Motor Label Dispenser
- Integrated Product Counter
- Suitable for Top & Side Labeling on Flat Surfaces
- Single-Touch Speed Adjustment
- User-Friendly Touchscreen (HMI) Interface
- Partial Machine Guarding for Safety
- Spring-Loaded Label Pressing Sponge Roller
- Built-In Control Panel for Easy Operation
- Pneumatic Carton Separation System
- Height-Adjustable Legs for Flexibility
|
|
|
Machine Size
|
1600(L)×1000(W)×1250(H)mm
|
|
Output Speed
|
20-100pcs/min depends on label and bottle size
|
|
Height Label Object
|
30-280mm
|
|
Bag size
|
max L60cm; max W 40cm; max H10cm
|
|
Label Height
|
15-140mm
|
|
Label Length
|
25-300mm
|
|
Pastes the sign precision
|
±1mm
|
|
Roll inside
|
76mm
|
|
Roll Outside Diameter
|
300mm
|
|
Power Supply
|
220V 0.8KW 50/60HZ
|
|
Power Supply
|
2800(L)×1650(W)×1500(H)mm
|
|
Weight of Labeling Machine
|
450Kg
|
List of Components
| List of Components |
| Description |
Brand |
| PLC |
Siemens |
| Touch Screen |
Siemens |
| Labeling head motor |
Panasonic |
| Transducer |
Delta |
| DC24V Electrical Source |
Delta |
| Checking Label Sensor |
Leuze |
| Checking bottle Sensor |
Keyence |
| Optical |
Keyence |
| SWITCH |
SCHNIDER |
| Emergency switch |
SCHNIDER |
Product Details
Product Application
After-sale Service
1. Installation
Our team of skilled technicians is available for on-site installation of the labeling machine. The service fee includes installation, travel, meals, and other related expenses.
2. Training
To ensure optimal machine performance, we provide comprehensive training for dealers, operators, engineers, and technicians—available either on-site or at our factory.
3. Warranty & Support
We offer efficient repair services with a one-year quality assurance period, ensuring timely parts supply and swift troubleshooting assistance.
4. Consulting Services
Take advantage of our free consultation with expert guidance from our sales team. We help you choose the best labeling solution, complete with custom CAD design support.
5. Technical Support
Enjoy 24/7 long-term technical support—simply reach out via email or phone for quick assistance, ensuring smooth operation without worries.
6. Spare Parts
A set of essential spare parts is included with your machine at no extra cost. Additional high-quality parts are available for order whenever needed.
